New Energy Vehicle Charging Pile Cable Solutions

Special Features

Low specific gravity, lightweight and completely halogen-free and environmentally friendly

Excellent resilience and appearance/feel.

It passes flame retardant tests according to various standards, exhibits good chemical resistance, water resistance, and outdoor weather resistance; it is a US standard insulation material that passes relative capacitance/stability factor tests and meets UL62/2263 requirements.

Typical Solutions and Physical Properties

Standards & Materials	GB/T33594	CQC 1103/04/05&DEKRA K175	TUV 2pfg1908	EN50620&IEC 62893	UL 62&2263	Typical Products
Sheath Materials
Regular TPE	S/S90	S	E	-	-	P663-75 P663-80H
US standard TPE	-	-	-	-	EVE/EVJE	P865-80
TPU	U	U/U1(EVM-1)	Q	EVM-1	-	U802-85MH
Insulating Materials
Regular TPE	S/S90	S/S90	E/E2	-	-	P663-85
US standard TPE	-	-	-	-	EVE/EVJE	P862-95
XLPE/XLPO	EY	E1(EVI-2)	Z	EVI-2	-	LSF25685

Typical products (sheaths)	P663-80H	U802-85MH(Sheath type)	P865-80
Material	TPE	TPU	TPE
Tensile strength / MPa	13.0	26.0	12.0
Elongation at break (%)	580	550	450
Hardness/shore A	81	86	81
Proportion	1.05	1.18	1.04
Temperature rating/°C	-40~105	-50~80	-60~105
Flame retardant rating (cables)	Single vertical burning	Single vertical burning	VW-1
Volume resistivity (Ω·cm@20°C)	>1×10¹⁵	>1×10¹¹	>1×10¹⁵
Typical Applications	Standard charging pile cable sheath	European standard charging pile cable sheath	US standard charging pile cable sheath

Typical products (insulation type)	P663-85	EF25685	LSF25285H	P862-95
Material	TPE	XLPO	XLPE/XLPO	TPE
Tensile strength / MPa	12.5	12.2	11.5	15.0
Elongation at break /%	480	600	380	400
Hardness/shore A	85	87	87	95
Proportion	1.06	1.10	1.21	1.05
Temperature rating/°C	-40~105	-40~105	-40~105	-60~105
Flame retardant rating (cables)	Single vertical flame retardant	Single vertical flame retardant	Single vertical flame retardant	WW-1
Volume resistivity (Ω·cm@20°C)	>1×10¹⁵	>1×10¹⁴	>1×10¹³	>1×10¹⁵
Typical applications	National standard charging pile cable insulation	Charging pile cable insulation	Charging pile cable insulation	US standard charging pile cable insulation
