High-voltage wiring harness solutions for new energy vehicles

Special Features

It has a delicate and soft texture and is completely halogen-free and environmentally friendly.

Passed the flame retardant test required by regulations.

Good chemical resistance and water resistance, suitable for various specifications and models.

Typical Solutions and Physical Properties

Typical Grades	P668-85Y	LSF25385H	EF5085G	P868-85GF
Material	TPE	XLPE/XLPO	XLPO	XLE
Tensile strength / MPa	13.5	11	11.5	15
Elongation at break /%	500	200	560	560
Volume resistivity / S²·cm (20°C)	>1*10¹⁵	>1*10¹³	>1*10¹³	>1*10¹⁴
Hardness/Shore A	86	86	87	88
High temperature pressure test / C	125	125	150	150
Proportion	1.01	1.28	1.09	1.05
Flame retardant rating (cables)	Single vertical	Single vertical	Single vertical	Single vertical
Temperature rating/°C	-50~125	-40~150	-40~150	-40~150
