Industrial Control/Specialty Cable Material Solutions

Typical Applications

Typical applications of TPU	Typical applications of TPE
Industrial Ethernet cable sheath	Robot/Drag Chain Cable Insulation
Robot/Drag Chain Cable Sheath	High-resilience cable sheath
Anti-mildew military-grade cable sheath	Halogen-free multi-core flexible cable sheath
Indoor flexible optical cable sheath	Flexible electromagnetic coil

Special Features

Halogen-free and environmentally friendly, it can replace PVC and other materials in more demanding environments.

TPU possesses excellent mechanical properties, with good resistance to bending and torsion. Custom modifications are available to enhance its resistance to water, chemicals, outdoor weather, mold, salt spray, and various harsh environments.

TPE has extremely high electrical insulation properties and a smooth, soft feel, making it suitable for various industrial cable applications.

典型解决方案及物性

Typical Grades	U802-85/Z	U802-85MZ	U808-85M	U802-93M
Material	TPU	TPU	TPU	TPU
Application	Industrial Ethernet cables	UL 105° VW-1 Flame Retardant Robot/Drag Chain Cable	Mold-resistant military-grade cables	Polyether type indoor flexible optical cable
Tensile strength / MPa	22.0	18.0	17.5	26.5
Elongation at break /%	450	500	480	530
Hardness/Shore A	86	87	85	93
Proportion	1.25	1.18	1.18	1.19
Flame retardant rating (cables)	Single vertical/VW-1	WW-1	Single vertical	Single vertical
Surface Appearance	Semi-matte	Semi-matte	Glossy/Semi-glossy	Semi-matte/Matte
Temperature Rating/°C	-50~90	-50~105	-50~80	-50~80

Typical Grades	K200-88	K220-75	P600-85	P800-75
Material	TPE	TPE	TPE	TPE
Application	Robot/Drag Chain Cable Insulation	High resilience cable sheath	Halogen-free (PVC alternative) sheathing material	Multi-core flexible cable flexible electromagnetic coil
Tensile strength / MPa	12.5	11.5	11.5	10.0
Elongation at break /%	450	650	300	430
Hardness/Shore A	88	75	86	75
Proportion	0.99	1.02	1.08	1.04
Flame retardant rating (cables)	-	-	Single vertical	Single vertical/VW-1
Surface Appearance	Semi-matte	Semi-matte	Semi-matte	Semi-matte
Temperature rating/°C	-60~105	-60~105	-40~90	-60~105
