Customized Material Solutions

Special Features

A wide range of substrates can be selected, and different substrates can be used independently or in combination, combining the advantages of various materials.

Without reference performance, based on the description of the application environment, general usage requirements, and extensive experience, various verification solutions can be recommended.

Based on high-end foreign materials, cost reduction through substitution, and targeted development.

"Tailor-made" customized technical services We respond quickly to market changes and customer demands.

Flame retardant Flame retardancy rating of material: HB → V-0, etc.

Hardness Shore hardness: 50A-95A and above (up to 40D-70D)

Temperature resistance Temperature range: -60~150℃, suitable for long-term use.

Color scheme Custom color schemes are provided based on customer samples, color cards, color difference data, etc.

Typical Solutions and Physical Properties

Various base materials are available.	定制性能	定制颜色	定制手感
Material	TPE	XLPE/XLPO	TPE
Tensile strength / MPa	12.5	11.5	15.0
Elongation at break /%	480	380	400
Hardness/shoreA	85	87	95
Proportion	1.06	1.21	1.05
Temperature rating/°C	-40~105	-40~105	-60~105
Flame retardant rating (cables)	Single vertical flame retardant	Single vertical flame retardant	VW-1
Volume resistivity / Q.cm (20°C)	>1*10¹⁵	>1*10¹³	>1*10¹⁵
Typical Applications	International charging pile cable insulation	charging pile cable insulation	US standard charging pile cable insulation
